Application Industries

  • Semiconductor wet process / UPW systems
  • Water treatment & environmental engineering
  • Chemical processing & corrosion control
  • Food & pharmaceutical processes

Material Selection Highlights

  • PVDF: high purity, chemical resistance, weatherability → wet-process piping/fixtures, pump/valve bodies, viewing windows.
  • PFA / PTFE: extreme chemical resistance → highly corrosive media, ultra-pure uses.
  • PEEK / PEEK+GF: high strength & heat → precision structures and wear parts.
  • PPS / PPS+GF: chemical resistance / flame retardant → electrical/electronic parts.
  • PP / PP+GF: lightweight & economical → general structures and chemical-resistant equipment.
PVDF Property Radar Chart
PVDF Property Radar

Chemical Resistance List

📋 PVDF Bolts Chemical Resistance Table (Click to Expand/Collapse)

✓ (Excellent)　△ (Limited)　X (Not recommended)　? (No data)

Category Chemical 20°C - 50°C 50°C - 80°C 80°C above
Organic Acids Acetic acid ✓ (80%) ✓ (80% @ 80˚C) △ (80% @ 100˚C)
Acetic acid, glacial ✓ ✓ (80˚C) △ (100˚C)
Acetic anhydride △ (25˚C) × (50˚C) ×
Citric acid ✓ ✓ ✓
Organic Compounds Acetaldehyde ? ? ?
Acetone △ (100% @ 25˚C) × (100% @ 50˚C) ×
Methyl alcohol ? ? ?
Aniline ✓ ✓ (80˚C) △ (100˚C)
Benzaldehyde ✓ (25˚C) △ (50˚C) ×
Benzene ✓ ✓ (80˚C) △ (100˚C)
Benzyl alcohol ✓ ✓ ✓
Benzyl chloride ✓ ✓ ✓ (100˚C)
Corn oil ✓ ✓ ✓
Ethanol ✓ ✓ ✓
Ethylene glycol ✓ ✓ ✓
Fatty acid ? ? ?
Formaldehyde ✓ ✓ (37% @ 80˚C) ✓
Formic acid ✓ (20%) ✓ ✓
Hexane ✓ ✓ ✓
Lactic acid ✓ (50˚C) △ (80˚C) × (100˚C)
Methanol ✓ ✓ ✓
Paraffin oil ? ? ?
Petroleum ✓ ✓ ✓
Phenol ✓ ✓ (100% @ 65˚C) △ (100% @ 80˚C)
Propane, liq ✓ ✓ ✓
Propanol ✓ ✓ (80˚C) △ (100˚C)
Stearic acid ✓ ✓ ✓
Tannic acid ✓ ✓ ✓ (110˚C)
Tartaric acid ? ? ?
Toluene ✓ ✓ (80˚C) △ (100˚C)
Urea ? ? ?
Inorganic Compounds Ammonia ? ? ?
Ammonium chloride ✓ ✓ ✓
Ammonium hydroxide ? ? ?
Ammonium nitrate ✓ ✓ ✓
Ammonium sulfate ✓ ✓ ✓
Aqua regia ? ? ?
Barium chloride ✓ ✓ ✓
Barium hydroxide ✓ ✓ ✓
Brine ? ? ?
Calcium chloride ✓ ✓ ✓
Calcium hydroxide ✓ ✓ ✓
Carbonic acid ✓ ✓ ✓
Chloric acid ? ? ?
Chlorine ✓ ✓ ✓ (100˚C)
Detergent ? ? ?
Hydrobromic acid ✓ ✓ ✓ (50% @ 100˚C)
Hydrochloric acid ✓ ✓ (20%) △ (35% @ 120˚C)
Hydrofluoric acid ? ? ?
Hydrogen peroxide ✓ ✓ (80˚C) ✓
Nitric acid ✓ ✓ (60% @ 65˚C) × (60% @ 100˚C)
Phosphoric acid ✓ (85%) ✓ ✓
Potassium hydroxide ✓ ✓ (80˚C) × (110˚C)
Potassium nitrate ✓ ✓ ✓
Potassium sulfate ✓ ✓ ✓
Sodium carbonate ✓ ✓ ✓
Sodium hydroxide ✓ (10˚C) × (40˚C) ×
Sodium nitrate ✓／△／× ✓／△／× ✓／△／×
Sulfuric acid ✓ ✓ ✓
Sulfur dioxide ✓ ✓ (98% @ 65˚C) × (98% @ 100˚C)

FAQ

See PVDF FAQs →
